Websockets

Using Bandit OTP and Plug

• Source Codegil-air-may/test-containers
• StackElixir / OTP / Bandit / Plug

Setting up a proper WebSockets server using Elixir isn't widely covered in tutorials. Most of the available information focuses on using the Phoenix framework with channels. While Phoenix is powerful, it may not be the right tool for a microservice approach. This small project will guide you through creating a barebones WebSockets setup using important concepts like Plug and OTP. As a bonus, instead of the typical Cowboy Erlang server, we'll use a more modern, pure Elixir server called Bandit.

Inside the backend folder, you'll find websocket_process.ex, which includes the Spike.WebsocketProcess module. This file is key to understanding the setup. Bandit creates processes to represent actual connections. The application then interacts with these processes using the callbacks shown below.

defmodule Spike.WebsocketProcess do
  alias Spike.ConnectionManager
  alias Spike.Message

  def init(conn) do
    id = get_id_from_conn(conn)
    IO.puts('New connection PID: #{inspect(self())}, ID: #{id}')
    ConnectionManager.add_connection(id, self())
    {:ok, conn}
  end

  def handle_in({client_message, [opcode: :text]}, state) do
    Message.handle_client_message(client_message)
    {:ok, state}
  end

  def handle_info({:text, server_message}, state) do
    {:push, {:text, server_message}, state}
  end

  def handle_info({:close, _code, _reason}, state) do
    id = get_id_from_conn(state.conn)
    ConnectionManager.remove_connection(id)
    {:ok, state}
  end

  defp get_id_from_conn(conn) do
    String.to_integer(conn.params["id"])
  end
end

Mapping Connections:

The init/1 function runs when a new websocket client connects to the server. It extracts the client ID from the connection and calls ConnectionManager.add_connection/2 which adds the ID/PID pair to a stateful map.

Server Messages:

To specify a target client, we simply send it to the process linked to that client's connection.

...
pid_map = ConnectionManager.get_conn_map()
pid_id_1 = pid_map[1]
Kernel.send(pid_id_1, {:text, payload})
...

This will trigger the handle_info/2 callback in Spike.WebsocketProcess, which relays the message to the client connection by returning a tuple with :push.

Client Messages:

Whenever a client sends a message, the application runs the handle_in/2 callback. You can insert any custom logic to handle updates from the client. In this example, the server expects a JSON message with the keys "target" and "payload". The function loops through the targets and the payload is sent to each connection associated with the target ID.

defmodule Spike.Message do
  alias Spike.ConnectionManager

  def handle_client_message(client_message) do
    client_message = Jason.decode!(client_message)
    Enum.each(client_message["targets"], fn target ->
      pid = ConnectionManager.get_connection(target)
      payload = Jason.encode!(client_message["payload"])
      Kernel.send(pid, {:text, payload})
    end)
  end
end

Final thoughts

This is a lightweight setup, and I've kept the example as simple as possible. However, it can serve as a solid foundation for more advanced WebSocket applications that require authentication and additional business logic. Happy coding!
